Glue Spreader
Place of Origin | Shandong, China |
Condition | New |
Type | Plywood Veneer Glue Spreader |
Weight (kG) | 33000 kg |
Applicable Industries | Building Material Shops, Manufacturing Plant,Home Use, Construction works , Energy & Mining. Other |
Warranty | More than 5 years |
Key Selling Points | Automatic |
Usage | Plywood Production |
Voltage | 380V/450V |
Video outgoing-inspection | Provided |
Warranty of core components | More than 5 years |
Core Components | Motor, PLC, Other, Engine |
Specification | 4ft double side glue spreader |
Quantity of roller | 4 |
Glue roller length | 1400mmm |
Rubber roller diameter | 245mm419mm |
Thickness of rubber | 18mm |
Diameter of steel roller | 217mm |
Rotary speed of roller | 45mlminladjustable |
Motor power | 3-4kW |
Dimension | 2100**1250*1400 |
Weight | 1.5ton |
Specification | 4ft double side glue spreader | 8ft double side gluing machine | 8ft pneumatic gluing machine double side |
Quantity of roller | 4 | 4 | 4 |
Glue roller length | 1400mmm | 2700 mm | 2700mm |
Rubber roller diameter | 245mm/419mm | 245/419 mm | 419mm |
Thickness of rubber | 18 mm | 20 mm | 20 mm |
Diameter of steel roller | 217 mm | 296 mm | 296mm |
Hard cromed on surface of steel roller | yes | yes | yes |
Rotary speed of roller | 45 m/min/adjustable | 45 m/min/adjustable | Adjustable |
Motor power | 3-4 kw | 5.5+11 | 7.5+7.5+1.5 |
Dimension | 2100*1250*1400 | 3400*1350*1600 | |
weight | 1.5 ton | 2ton | 4.6 ton |
Features:
1.Coated roller with high quality natural rubber with high mechanical strength, hardness suitable, good wear resistance, good aging resistance, long service life.
2.Steel roller with high-quality thick-walled seamless steel pipe, hard chrome plated and uniform, the surface to do mirror
treatment, and then by grinding and other fine processing from Smooth operation, uniform coating, cost savings.
3.The use of the bottom of the hopper design, do not repeatedly add glue, the province of clean labor, a substantial increase in efficiency.
4.Gearbox for the gear, chain mirror with the drive, stable and reliable and durable.
5.The roller speed by the adjustable motor fine-tuning, control and stability.
6.Roller squeeze force balance, the object received rolling pressure uniformity.
7.Repeat the roll of the same roller and roll force.
8.According to the specific needs of the work to roll the speed of adjustment.
9. the whole machine-wide steel structure, with a door-type shield.
Purpose:
Widely used in plywood factory, furniture factory and sound equipment factory, stickers factory.
FAQ:
1. Can you customize products for clients?
Yes, We can customize and produce woodworking machines according to the customer’s requirements or drawings.
2. How can we trust your factory?
We recommend that you come to our factory to see the goods, to verify the real situation of the products, and know more about our factory.
3.Why does the price often change?
The price depends on the latest prices of the raw materials.
4. What about the contract signing?
If you’re satisfied with the products and our service, you can sign the contract with us, pay the deposit. Then we’ll produce the machines as soon as possible. If you are far away, we can sign the contract by fax. We will ensure the quality of the products and the accessories are complete.
5. How about delivery?
When the product is ready, it can be delivered to you after your full payment. We’ll provide technical guidance.
